Technical Specifications
System
CPU :
Intel® Celeron j1900 / Intel® Icore i5/i7
Cache :
2nd Level depends on CPU
Memory :
4GB
Video RAM :
Max 128 MB shared memory
Control :
Intel® Soc / QM77
Watchdog Timer :
255 Level Reset
System Fan :
N.A.
I/O
Serial Port :
4 x RS-232 Ports
USB Port :
4 x USB 2.0
LAN :
2 x LAN Realtek Gigabit Ethernet
Audio :
Line in & out (AC’97 codec audio)
Data Storage
HDD / Type :
Vibration Resistant Slot 2.5 ”(500 GB HDD)
SSD :
64 GB / 128GB / 256 GB
Feed
Input :
220VAC or 24VDC
Extra Video Output
Type :
HDMI/DP/DVI/VGA (Optional)
Max. Resolution :
1920x1080(2560x1600 Optional)
LCD Screen
Type and Size :
27" LVDS
Max. Resolution :
1920x1080
Pixel Pitch :
0.311mm x 0.311mm
Max Color :
16.7 M
Brightness (cd/m2) :
300cd
Contrast Ratio :
1000/1
Viewing Angle :
160°(H),160°(V)
Back Light MTBF :
50,000 hours
Mechanical & Environmental Features
Operating Temperature :
0 ~ 60°C
Storage Humidity :
5 ~ 95% (non-condensing)
Case :
Heavy-Duty Metal Case
Front Frame :
Metal Frame / Glass (Optional
Weight :
Variable according to screen size (1—5 kg)
Dimensions :
Variable according to screen size (1—5 kg)
Mounting :
Surface Mount / Built-in
Order Code
CPU :
J1900, i5, 7
PSU :
AC - 220VAC
RAM :
R4
HDD :
HDD 500GB(OPS), SSD64, SSD128, SSD256
Wifi :
N.A
