Technical Specifications
System
Cache :
N.A.
Memory :
2GB
Video RAM :
N.A.
Control :
N.A.
Watchdog Timer :
Support
Android OS :
Android 8.0
Processor :
4x ARM Cortex-A17 @ 1.61 GHz
I/O
Serial Port :
N.A
USB Port :
2 x USB 2.0
LAN :
1x Lan
Wireless LAN :
802.11 b / g (Optional)
Audio :
Support L/R phone jack and 10W / 8Rx2
Data Storage
Memory :
2GB
EEMC :
16GB Flash
HDD / Type :
N.A
SSD :
N.A
Feed
Input :
220VAC
Extra Video Output
Type :
HDMI (Optional)
Max. Resolution :
1920x1080(Optional)
LCD Screen
Type and Size :
49" LVDS
Max. Resolution :
1920x1080
Pixel Pitch :
0.311mm x 0.311mm
Max Color :
16.7 M
Brightness (cd/m2) :
300cd
Contrast Ratio :
1000/1
Viewing Angle :
160°(H),160°(V)
Back Light MTBF :
50,000 hours
Mechanical & Environmental Features
Operating Temperature :
0 ~ 60°C
Storage Humidity :
5 ~ 95% (non-condensing)
Case :
Heavy-Duty Metal Case
Front Frame :
Metal Frame / Glass (Optional)
Weight :
Variable according to screen size (1—5 kg)
Dimensions :
(WxHxD) Variable by screen size
Mounting :
Surface Mount / Built-in
Order Code
CPU :
Cortex A53
PSU :
AC - 220VAC
RAM :
R2
HDD :
EEMC 16GB Flash
Wifi :
Optional
