Technical Specifications
System
CPU :
Intel® Celeron® Processor J1900
Cache :
2nd Level depends on CPU
Memory :
2 x DDR3 SoDIMM max. 4GB / 8GB
Video RAM :
Intel® Gen7 Intel® Graphics DX 11
Control :
Intel® Soc
Watchdog Timer :
255 Level Reset
System Fan :
N.A.
I/O
Serial Port :
3 x RS-232 ports
Parallel Port :
N.A.
USB Port :
4 x USB 2.0
KB / MS :
1 x PS2 K/B and Mouse
LAN :
1 x LAN Realtek Gigabit Ethernet,
Wireless LAN :
802.11 b / g (Optional)
Audio :
Line in & out (AC’97 codec audio)
Expansion Slot :
MiniPCIe
Data Storage
HDD / Type :
2.5” HDD/SSD
Feed
Input :
110 / 220VAC - 12 / 24VDC - PoE
Extra Video Output
Type :
HDMI/DVI
Max. Resolution :
1920x1080
LCD Screen
Backlight Half-Life :
30,000 hours
Type and Size :
10.1” / LVDS
Max. Resolution :
1280 x 800
Pixel Pitch :
0.297mm x 0.297mm
Max Color :
16.7 M
Brightness (cd/m2) :
400cd
Contrast Ratio :
700/1
Viewing Angle :
170°(H),170°(V)
Touch Screen :
10.1” - Capacitive Touch ( Optional )
Mechanical & Environmental Features
Operating Temperature :
0 ~ 60°C
Storage Humidity :
5 ~ 95% (non-condensing)
Case :
Heavy-Duty Metal Case
Front Frame :
Glass/Metal
Weight :
Variable according to screen size (1—5 kg)
Dimensions :
(WxHxD) Variable by screen size
Mounting :
Built-in
Order Code
CPU :
J1900
PSU :
AC110/220, DC12/24, PoE
RAM :
R4, R8, R16
HDD :
HDD 320 GB, SSD32, SSD64
Wifi :
Optional
