TPC-310 Series

10.1'' Door Signage Display

CureVision Door Information Displays are meticulously crafted to seamlessly integrate with your corporate identity and architectural aesthetics, serving as invaluable tools for guidance and information within healthcare facilities. Ideal for deployment in polyclinics, meeting rooms, and conference rooms, these displays offer a perfect blend of functional excellence and visual sophistication.

Key Features:

Dynamic Information Publication: Keep patients, visitors, and staff informed with real-time updates and announcements displayed prominently on CureVision Door Information Displays. Facilitate efficient communication by delivering crucial information where it matters most.

Bespoke Design for Institutional Identity: Enhance the visual appeal of your healthcare institution with our Door Information Displays, uniquely designed to align with your corporate identity and architectural decor. Create a cohesive and professional ambience.

Robust Industrial Stainless Case: Built to withstand the demands of healthcare environments, the displays feature a durable industrial stainless case, ensuring longevity and reliability even in high-traffic areas.

Wide Operating Temperature Range: From the chill of waiting areas to the warmth of meeting rooms, CureVision Door Information Displays operate flawlessly within a broad temperature range from 0 to 60°C, ensuring consistent performance in diverse settings.

Instant Remote Support: Experience unparalleled support with instant connection analysis and solution assistance through remote connectivity. This feature enables swift issue resolution, minimizing downtime and maximizing the functionality of the displays.

Elegant Design
Elegant Design
Customizing with Corporate Color and Logo
Customizing with Corporate Color and Logo
Durable and Long Lasting
Durable and Long Lasting

Sectors

Technical Specifications

System
CPU :
Intel® Celeron™ Processor J1900 Low Power Fanless
Cache :
2MB
Memory :
2 x DDR3 SoDIMM max 4GB / 8GB
Video RAM :
Max 128 MB shared memory
Control :
N.A.
Watchdog Timer :
255 Level Reset
System Fan :
1 x 4cm / 10CFM
I/O
Serial Port :
3 x RS-232 ports
Parallel Port :
N.A.
USB Port :
4 x USB 2.0
KB / MS :
1 x PS2 K/B and Mouse
LAN :
1 x LAN Realtek Gigabit Ethernet,
Wireless LAN :
802.11 b / g (Optional)
Audio :
Line in & out (AC’97 codec audio)
Expansion Slot :
MiniPCIe
Data Storage
HDD / Type :
2.5” HDD/SSD
Feed
Input :
110 / 220VAC - 12 / 24VDC - PoE
Extra Video Output
Type :
HDMI
Max. Resolution :
1920 x 1080
LCD Screen
Type and Size :
10.1” / 16:9
Max. Resolution :
1280 x 800
Pixel Pitch :
0.297mm x 0.297mm
Max Color :
16.7 M
Brightness (cd/m2) :
250cd
Contrast Ratio :
700/1
Viewing Angle :
160°(H),160°(V)
Back Light MTBF :
50,000 hours
Touch Screen :
10.1” Capacitive Touch
Mechanical & Environmental Features
Operating Temperature :
0 ~ 60°C
Storage Humidity :
5 ~ 95% (non-condensing)
Case :
Heavy-Duty Metal Case
Front Frame :
Glass
Weight :
Variable according to screen size (1—5 kg)
Dimensions :
(WxHxD) Variable by screen size
Mounting :
Built-in
Order Code
CPU :
J1900
PSU :
AC110/220, DC12/24, PoE
RAM :
R4, R8
HDD :
HDD 320GB, SSD 32 GB, SSD 64 GB
Wifi :
Optional

Support

Please contact us for information about the products or for technical support.
